Villa Composting Toilet by Separett
The Separett Villa Composting Toilet, previously known as the Separett Villa 9215 and Separett Villa Us, is the ultimate solution for eco-conscious individuals seeking a sustainable and convenient waste management system. Designed with advanced technology and user-friendly features, this waterless, urine-diverting toilet offers a seamless and hygienic experience, perfect for off-grid, vacation homes, or residential settings. Its sleek design ensures an odor-free and environmentally friendly solution, with a strong 12V fan capable of handling installations up to 6 meters long with up to three 90° bends.
Operable with 110-240V AC or 12V DC solar cell/battery power, the Separett Villa is ideal for on-grid or off-grid living. The fan's low energy consumption (0.06 kWh/24h) makes it suitable for battery or solar operation. Its simplicity and unlimited capacity provide a comfortable and hassle-free toilet visit, reducing both the smell and volume of waste through efficient urine separation.
*Battery and battery cables are not included.
Separett Villa User Manual and Installation Guide
Separett Villa Features
Odorless and Silent
The Separett Villa is designed with an efficient and quiet fan to give you the best toilet experience by providing optimal airflow. The Fan's energy consumption is very low and is only at 0.06kWh/24 hours which makes it suitable for battery and solar operations as well.
Waterless Toilet
The Separett Villa is a waterless toilet making it the perfect toilet solution for regular homes, tiny houses, RVs, boats, and even any remote and off-grid locations. Being waterless means no plumbing involved, therefore you are saving time and money with this toilet that offers simplicity and effectiveness at the same time.
Urine Diverting Technology
Designed with Urine-diverting technology, the Separett Villa is able to achieve the best conditions to enhance the composting process. By separating solid and liquid waste you get less composting time, reduced odor, and less waste volume.
High Capacity Composting Toilet
Even with alternating and continuous use, the Separett Villa is sure to meet your Toilet Needs. With its High Capacity, the Villa is suitable for both leisure and permanent living. To give you a better picture, the Villa can accommodate a home with five people and you will only need to empty the container every 4 to 6 weeks.
For more capacity, an extended version of the villa is also available, The Separett Villa Extend, comes with a funnel that you can lead to an external chamber underneath the floor for solid waste.
User Friendly and Cost Efficient
The Separett Villa is a User-Friendly Composting toilet. Installation, usage, and maintenance are very easy to follow. Since no plumbing is required and the Villa complete with the instructions, installation can be done by anyone within a matter of minutes. Low energy consumption fan, no plumbing service required, and a waterless toilet, the perfect trio for a cost-efficient composting toilet that pays for itself over time.
Separett Villa Specs
| Capacity | Unlimited - need for emptying depends on the amount of users |
|---|---|
| Product weight | 42 lbs |
| Package weight | 46 lbs |
| Max user weight | 330 lbs |
| Product measurements | L 26.5" W 19" H 21.3" |
| Seat height | 17.3" |
| Box size | L 30.3" W 18.5" H 26" |
| Material | Polypropylene (PP), high gloss, recyclable |
| Emptying interval with 4 users (liquids) | When the container is full (if used) |
| Emptying interval with 4 users (solids) | When the container is full (if used) |
| Energy consumption | 0.06 kWh / 24 h |
| Power adapter | 110-240 V universal adapter |
| Total effect | 12 V / 2.5W / 210 mA |
| Voltage | 12 V |
| Ventilation duct | Ventilation pipe ⌀3.5" standard |
| Urine pipe | Urine pipe ⌀1.26" |
| Noise level in use | less than 30 dB(A) |
Separett Villa Inclusions
Separett Villa
- Separett Villa® toilet, 12V / 110-240 V
- User and installation manual
- Universal adapter for power socket
- 1 x solid waste container
- 1 x lid for waste container
- Straight connector piece to fit the 90° bend
- 90° bend for the Ø3.5” ventilation pipe
- 1.47” long Ø3.5” pipe for simple ventilation installation through the wall
- Insect net and rain cap for Ø3.5” ventilation pipe
- Indoor flashing for the Ø3.5” ventilation pipe
- 6.6 ft white urine hose Ø32 mm to lead out the urine
- Indoor flashing for the Ø1.26” urine hose
- 90° bend for the Ø1.26” urine hose
- Straight connector for the Ø1.26” urine hose
- Silicone strip to seal the bottom of the toilet
- Wall mount for attaching the toilet
- 2 x wall mount to attach the urine hose
- Screws for mounting the toilet to the wall or to the floor
- A sample of Bioblock – used to prevent blockage in the internal urine hose
- A sample of Absorb – used to prevent excess moisture in the solids container
- A sample of Compostable waste bags – used in the solid waste container to collect waste
- Installation template – has markings for drilling holes and attaching the toilet
Separett Villa Extend
- Separett Villa® Extend toilet, 12V / 110-240 V
- User and installation manual
- Universal adapter for power socket
- Straight connector piece to fit the 90° bend
- 90° bend for the Ø3.5” ventilation pipe
- 1.47” long Ø3.5” pipe for simple ventilation installation through the wall
- Insect net and rain cap for Ø3.5” ventilation pipe
- Indoor flashing for the Ø3.5” ventilation pipe
- 6.6 ft white urine hose Ø32 mm to lead out the urine
- Indoor flashing for the Ø1.26” urine hose
- 90° bend for the Ø1.26” urine hose
- Straight connector for the Ø1.26” urine hose
- Silicone strip to seal the bottom of the toilet
- Wall mount for attaching the toilet
- 2 x wall mount to attach the urine hose
- Screws for mounting the toilet to the wall
- Installation template – has markings for drilling holes and attaching the toilet
How to Clean and Maintain the Separett Villa
Separett Villa FAQs
Can you Extend the Separett Villa's Ventilation Pipe
Yes, you can. You can extend it up to 20ft of ventilation piping and three 90-degree bends.
Do you need a Fresh Air Valve for the Separett Villa?
No, you do not need a Fresh air Valve. The Villa is designed to perform well even with just the air supply coming from your windows and doors. Adding another fan will cause issues and may create a vacuum effect.
Can you lead the ventilation pipes to a chimney stack?
This is only recommended if the chimney stack is no longer in use and if there is a plastic used within the chimney stack. It is not recommended to lead the airflow freely in the chimney stack since moisture from the bathroom may destroy the mortar joints.
Do you need to insulate the ventilation pipes of the Separett Villa?
No, you do not need to insulate the Ventilation Pipes. The Villa is built with a condensation water collector, which leads the water to the urine outlet.
Do you need a Trap for the Urine Outlet of the Separett Villa?
You do not need one in most cases. You only need one if the odor from your wastewater system gets through the toilet room.
Is it okay to use the Separett Villa without the Fan?
It is not recommended to use the Separett Villa without the fan. Without the Fan, unpleasant odor will build up and flies may lay eggs on the solid waste container. With the fan on you can prevent all these and waste also dries better and faster.
How to clean the Separett Villa?
The Solids container for the Separett Villa can be cleaned like any other plastic container. Make sure to use non-corrosive substances when cleaning your Separett Villa Toilet.
