Rich Solar BRAVO 30 30 Amp MPPT Solar Charge Controller

Rich Solar MPPT Charge Controller – Precision Power for Your Solar Setup

Overview
Get more out of your solar investment with the Rich Solar MPPT Charge Controller, designed for both performance and protection. Featuring advanced True MPPT technology and intelligent system adaptation, this controller ensures ultra-efficient power conversion—even in shaded conditions. With customizable charging, multi-battery compatibility, and optional remote monitoring, it gives you full control over your solar system. Whether you're powering a tiny home, cabin, or RV, this charge controller delivers safe, smart, and reliable energy management in every environment.

Features

1. Advanced MPPT Technology

   • True MPPT with the latest tracking algorithm

   • Tracking efficiency over 99.5%

   • Multi-peak detection enhances output in partially shaded conditions

   • Charge conversion efficiency up to 98%

2. Intelligent System Compatibility

   • Automatically detects 12V or 24V system voltage

   • Supports a wide range of battery types:

     • Lead-Acid: Gel, AGM, Wet, Crystal, Calcium

     • Lithium: LiFePO₄, LTO, LCO

   • Optional external battery temperature sensor for improved lithium safety and performance

3. Advanced Protection System

   • Triple-layered protection: over-voltage, reverse discharge, and short-circuit prevention

   • Lithium battery activation feature for deeply discharged cells

   • Conformal-coated internal electronics (IP43) and IP22-rated connection ports

4. Precision Charging Control

   • Fully customizable charge settings for battery optimization

   • Built-in performance data storage

   • Proprietary charge algorithms to extend battery life and efficiency

5. Intelligent Monitoring System

   • Integrated LCD shows solar input, battery voltage, charging status, and custom settings

   • LED status bar for quick at-a-glance system diagnostics

   • Optional internal Bluetooth and remote digital display for wireless monitoring

Specifications

• Technology: True MPPT with multi-peak detection

• System Voltage: 12V / 24V auto-recognition

• Tracking Efficiency: >99.5%

• Charge Conversion Efficiency: Up to 98%

• Battery Compatibility:

  • Lead-Acid: Gel, AGM, Wet, Crystal, Calcium

  • Lithium: LiFePO₄, LTO, LCO

• Protection Features:

  • Over-voltage

  • Reverse discharge

  • Short-circuit

  • Lithium battery recovery

• Environmental Ratings:

  • IP43-rated internal board

  • IP22-rated connection ports

  • Conformal-coated circuit board

• User Interface:

  • LCD display + LED status indicators

  • Optional Bluetooth module

  • Optional external digital remote display

• Additional Options: External battery temperature sensor

• Certifications: Designed in compliance with UL1741, EN/IEC 62109-1

• Manufacturing: In-house design and production with comprehensive electronic protections
